Baader UFC Camera-Sided Adapters

Please see Technical Specifications for more detail about each part!

Versatile application for almost any telescope / camera.

The camera-side of the UFC-Base (the filter-chamber) remains open towards the camera - until the matching camera-adapter gets mounted directly onto the UFC-Base. The purpose of this is to have the filters mounted with minimum distance to the image sensor, avoiding additional vignetting.

Camera-Sided Adapters:

UFC protective EOS T-Ring Adapter, S52 dovetail connects to T-Ring w/ Mounting plate
UFC T-Adapter, connects to camera T-Ring with Mounting plate for UFC Base
UFC M48 Adapter, (optical height: 2 mm) M48 (m) thread facing camera with Mounting plate for UFC base
UFC 2" SC Adapter, (optical height: 2 mm) 2" (m) thread facing camera w/ Mounting plate for UFC Base
UFC FLI Adapter, (optical height: 10 mm) connects to FLI camera, for ML and PL Flange w/Mounting plate
UFC M54 Adapter,(optical height: 2 mm) M54x0.75(m) thread facing camera w/ Mounting plate for UFC Base
UFC M68 Adapter,(optical height: 5.5 mm) M68 x 1 (f) thread facing camera w/mounting plate for UFC Base
UFC M72 (m) Camera-Adapter (optical height: 2 mm)
UFC Straylight Flange when mounting UFC in front of camera lenses incl Mounting plate for UFC Base

For any telescope, for any camera - just replace the corresponding adapters on either side of the filter chamber when you change telescope or camera and want to keep on using your trusted set of filters.

As added benefit any camera lens can be used with the UFC. In this case, the UFC-Base will be fastened in front of the camera-lens with adding both the S70/SP54 adapter #2459134 and the retaining flange #2459121, as well as one of the many step-rings of the Hyperion-ring-system (#2958028 - 2958082) to be found here. Note that filters ought to be mounted in reverse order when using the UFC-filter changer in front of camera lenses.
